Fencing and Panel Systems

Obrázok hlavičky produktu - Fencing and Panel Systems | vomet.sk

Fencing and Panel Systems

TYPE D-1

DESCRIPTION

D-1 panel systems are modern products of above-standard quality, which is possible to adapt to any natural conditions (curvature, corners, height differences, angles). The unique system of fastening the panels to the post profiles enables their fast and easy installation. The hot-dip galvanizing and the powder coating layer ensure their very good corrosion protection. The difference between D-1 and D-2 panel fencing lies in the height and width of the fold.

USE

With their aesthetic and functional design, they are an ideal solution for fencing of family houses, companies, production halls, businesses, parks, schools as well as sport facilities.

COLOUR

Customers have a possibility to choose from more than 200 colours from RAL scheme. They can also choose a different colour for each part of the panel fencing.

ASSEMBLY

  • Field Installation

  • Field Installation with the possibility of using a fence bottom barrier

  • Mounted on a solid (concrete) base using anchor plates

ACCESSORIES

  • Gates and wickets

  • Posts

  • Bottom barrier

  • Fittings

  • Barbed wire

SPECIFICATION (TECHNICAL PARAMETERS)

Panel width: 2500 mm

Wire diameter:

  • Type D-1: horizontal wire Ø 5mm, vertical wire Ø 5 mm

  • Type Lekki D-1: horizontal wire Ø 5mm, vertical wire Ø 4 mm

Mesh size: 50 x 200 mm

Height of the panel: 1.0 m, 1.2 m, 1.5 m, 1.67 m, 1.8 m, 2.0 m

Post profile: 40 × 60 × 2 mm (standard)

Product 1 - Image 1

REFERENCES

TYPE D-2

DESCRIPTION

D-2 panel systems are modern products of above-standard quality, which is possible to adapt to any natural conditions (curvature, corners, height differences, angles). The unique system of fastening the panels to the post profiles enables their fast and easy installation. The hot-dip galvanizing and the powder coating layer ensure their very good corrosion protection. Becasuse of larger number of folds, the type D-2 has a higher tensile strength which allows its use up to almost 2.5 m height. The difference between D-1 and D-2 panel fencing lies in the height and width of the fold.

USE

With their aesthetic and functional design, they are an ideal solution for fencing of family houses, companies, production halls, businesses, parks, schools as well as sport facilities.

COLOUR

Customers have a possibility to choose from more than 200 colours from RAL scheme. They can also choose a different colour for each part of the panel fencing.

ASSEMBLY

  • Field Installation

  • Field Installation with the possibility of using a fence bottom barrier

  • Mounted on a solid (concrete) base using anchor plates

ACCESSORIES

  • Gates and wickets

  • Posts

  • Bottom barrier

  • Fittings

  • Barbed wire

SPECIFICATION (TECHNICAL PARAMETERS)

Panel width: 2500 mm.

Wire diameter:

  • Type D-2 horizontal wire Ø 5 mm, vertical wire Ø 5 mm

  • Type lekki D-2 horizontal wire Ø 5 mm, vertical wire Ø 4 mm

Mesh size: 50 × 200 mm.

Panel height: 1.05 m; 1.150 m; 1.550 m; 1.850 m; 2.050 m; 2.250 m; 2.450 m.

Post profile: 40 × 60 × 2 mm (standard).


REFERENCES

TYPE D-3

DESCRIPTION

D-3 panel systems are modern products of above-standard quality, which is possible to adapt to any natural conditions (curvature, corners, height differences, angles). The unique system of fastening the panels to the post profiles enables their fast and easy installation. The hot-dip galvanizing and the powder coating layer ensure their very good corrosion protection. D-3 panel parts are characterized by a high degree of protection because the individual panels are at the top finished by vertical wires up to the height of 30 mm.

USE

The massive construction of D-3 panel systems is characterized by a high degree of rigidity. It predestines them for the protection of sensitive security zones, logistic centres, military buildings, administrative facilities or power plants.

COLOUR

Customers have a possibility to choose from more than 200 colours from RAL scheme. They can also choose a different colour for each part of the panel fencing.

ASSEMBLY

  • Field Installation

  • Field Installation with the possibility of using a fence bottom barrier

  • Mounted on a solid (concrete) base using anchor plates

ACCESSORIES

  • Gates and wickets

  • Posts

  • Bottom barrier

  • Fittings

SPECIFICATION (TECHNICAL PARAMETERS)

Panel width: 2510 mm

Wire diameter:

  • Type D-3 horizontal wire (double) Ø 5 mm, vertical wire Ø 6 mm

Mesh size: 50 × 200 mm

Panel height: from 630 mm to 2450 mm

At the top finished by vertical wires of 30 mm length

Post profile: 60 × 60 × 2 mm (standard)

Consultancy and advisory services


How to choose the right product?

If you need advice, don't hesitate to ask!

We will answer your questions and help you with every step in the selection of material as well as project implementation.

  • We provide technical information and documentation
  • We provide advice on the right selection and use of materials
  • We provide technical recommendation and solutions
  • Consultation on application and suitability of our products
